FEP Heat Shrink Tubing - 2:1
FEP Heat Shrink Tubing - 2:1
| Sycor Part No | Material | Standard Wall Thickness | Min. I.D Expanded As Supplied | I.D. Will Shrink to at least | |
|---|---|---|---|---|---|
| T2P.385 | FEP 2:1 | 0.013 ± 0.0025 | 0.385 | 0.1925 |
|
| T2P.290 | FEP 2:1 | 0.013 ± 0.0025 | 0.290 | 0.145 |
|
| T2P.180 | FEP 2:1 | 0.013 ± 0.0025 | 0.180 | 0.095 |
|
| T2P.125 | FEP 2:1 | 0.013 ± 0.0025 | 0.125 | 0.063 |
|
| T2P.075 | FEP 2:1 | 0.013 ± 0.0025 | 0.075 | 0.0375 |
|
| T2P.034 | FEP 2:1 | 0.013 ± 0.0025 | 0.034 | 0.017 |
|
Available in various spool lengths or sticks.
Please contact us to enquire.
Description of FEP Heat Shrink Tubing:
Sycor’s high-quality Teflon© FEP heat shrink tubing provides insulating, mechanical and chemical protection. FEP heat shrink offers a lower cost solution where high shrink ratios are not required and shrinks at a lower temperature than most materials. Clear FEP heat shrink tubing remains clear after shrinkage to allow inner components to be seen.
For our comprehensive list of heat shrink options, click here.
Temperature Rating of FEP Heat Shrink Tubing:
-200°C to +200°C
Shrinks at: 200°C
Approvals of FEP Heat Shrink Tubing:
UL224
Construction of FEP Heat Shrink Tubing:
Fluorinated Ethylene Propylene (FEP) heat shrink tubing
Application of FEP Heat Shrink Tubing:
FEP heat shrink tubing is a cost-effective choice for applications in aerospace, fibre optics, medical and automotive industries for electrical insulation; mechanical, chemical and other environmental protection of in-line components, terminals or splices. FEP heat shrink offers greater flexibility and clarity at lower shrink temperatures.
Shrink Ratios Available:
Colour options for FEP Heat Shrink Tubing:
Value-Added Services for FEP Heat Shrink Tubing:
All specifications are provided for reference only. Specifications will vary between manufacturers and are subject to change without notice. Be sure to check with your sales rep for the most accurate and up to date information when ordering.
